RAP250/350/500
Proteus Motorized Cable Reel
Built to the same exacting standards as our manual cable reels, these labour saving motorized reels are sturdy, rugged and built to perform reliably efficient pipeline inspections.
Minicam motorized cable reels are designed for easy one-person operation in remote locations. The reels are fitted with high tensile strength Kevlar reinforced inspection cable. The ultra-smooth operation is provided by the powerful three phase motor and cable layering mechanism for uninterrupted, tangle free pay-out and re-winding. A rigid, clear safety screen prevents contact with the cable whilst coiling.
Specification
RAP250 DIMENSIONS
20.8” x 12.5” x 20.5”
RAP250 WEIGHT
72 lbs
RAP350 DIMENSIONS
20.8” x 17.3” x 20.5”
RAP350 WEIGHT
92 lbs
RAP500 DIMENSIONS
20.8” x 17.3” x 20.5”
RAP500 WEIGHT
111 lbs
Safety Screen
A clear safety screen prevents contact with the cable whilst coiling.
Three Phase Motor
The ultra-smooth operation is provided by the powerful three phase motor and cable layering mechanism for uninterrupted, tangle free pay-out and re-winding.
Fixing Points
Fixing points to fit Portable Storage Trolley.
The reel is operated using the dedicated keys and intuitive on-screen display on the Proteus CCU.
In the event of an emergency, the reel also features an emergency stop button. The specialized Tractor connector provides a waterproof seal and there’s a removable drip tray for easy cleaning an maintenance.
Motorized reels are available in 3 sizes – Small = 820 ft, Medium = 1150 ft and Large = 1640 ft. The 820 ft reel has secure fixing points for fitting to our PTP02 Portable Storage Trolley.
