Micron Standard Camera Reel
Micron camera reels are the ideal camera for small jobs. Lightweight at only 16 lbs with 100 feet of premium 1/4″ push rod.
Meet Micron
Micron camera reels can be used with either Hathorn control modules (H12+ recommended), or with your own mobile Apple/Android device, should you opt for the Wi-Fi option. The Wi-Fi option is a standalone camera system that allows live streaming and recording to up to three devices at the same time using Hathorn’s free app. It is powered by an external Milwaukee® 18V or equivalent battery (sold separately), which can last over 12 hours.
Inspect pipes from 1.5” to 3” with ease. 1" straight view camera head with auto-iris technology
Lightweight, can go anywhere - weighs only 16lbs and 16" tall.
Specification
DIMENSIONS
16" x 12" x 10"
WEIGHT
15lbs. (6.8Kg) without battery
Micron reels are trusted by plumbers, general contractors, and home inspectors to deliver crystal clear, recordable video inspections of small pipes 1.5″ to 3″. These reels offer a butt-welded steel frame construction and 100 ft of premium 1/4″ push rod. Both styles of reel come equipped with 1″ straight view camera heads fitted with super bright, cool running LEDs for optimal picture quality.
Compatibility
All Hathorn Control Units
Push Rod
with premium 1/4″ rod with HDPE jacket
Sonde
512Hz High-power sonde
Power
Powered using
Hathorn Control Units
Non-Dimmable Lighting
8 super bright cool running LEDs for long camera lufe – 8000 Lux at 6″
Camera Head
1″ straight view camera heads with auto-iris technology
Operating Temperature
-22ºF to 140ºF (-30ºC to 60ºC)
Water Resistance
IP65
| Catalog | Camera Head | Wi-Fi | Self Leveling | Rod Length | Rod Size | Min 90º Elbow | Weight | Max Pipe | Dimensions |
|---|---|---|---|---|---|---|---|---|---|
| MC-1100 | 1" | Yes | No | 100ft | 1/4" | 1.5" | 16lbs | 3" | 16" x 12" x 10" |
| MC-1078 | 7/8" | Yes | No | 100ft | 1/4" | 1.5" | 16lbs | 3" | 16" x 12" x 10" |
Upgrade to Hathorn
Micron drain camera reels can be used with any Hathorn control module (non-Wi-Fi) or used with your own mobile Apple/Android device, if you choose the Wi-Fi stream/record option. The Wi-Fi option is a standalone Drain Inspection Camera System that allows live streaming and recording to up to four devices at the same time.
